Cam bush set - 10C5808


Artikel 11 van 1472
Tijdelijke aanbieding [NIEUWTAG]
  • Onze klanten waarderen ons met een 9.3 / 10
  • Gratis verzending boven € 250,- (NL-BE-LU)
  • MEER DAN 85.000 CAR-TUNINGS PARTS
  • 14 dagen bedenktijd*
    Uitzondering maatwerk- en speciaal bestelde producten
  • Heeft u vragen? BEL: +31 36 844 77 00
  • Live chat Support online
  • Veilig online betalen

Omschrijving
Split Cam Type insert

Product specificatie

  • Half type: Identical halves
  • Tunnel mm: No Data
  • Shaft mm: No Data
  • Max. Wall: No Data
  • Max. Length: No Data
  • Max. Length: 0.21

De levertijd staat op 3-7 werkdagen, dit is geldt alleen als de lagers op voorraad zijn in Nederland, wij updaten u direct na order, heeft u haast neem dan contact op met ons per telefoon of email voor de beschikbaarheid van de door uw benodigde applicatie. (levertijd vanaf de fabriek kan oplopen tot 2-3 weken, of langer indien geen voorraad)

  • Prefixes explained
  • H - ACL Race Series.(oe replacement)
  • HX - ACL Race Series with 0.025mm (.001”) extra clearance.
  • HD - ACL Race Series with location dowel holes.
  • HXD - ACL Race Series with 0.025mm (.001”) extra clearance and location dowel
  • HC - ACL Race Series Calico Coated
  • HXC - ACL Race Series with 0.025mm (.001”) extra clearance. Calico Coated

Oil clearances are most accurately measured using micrometres and bore gauges.
Bearing wall thickness measurements are taken at 90 degrees to the partingline (i.e. at the crown of the bearing) using a micrometre with a ball anvil, for use on the curved ID of the bearing.
Vertical oil clearance is best measured by assembling the bearing in its housing, with bolts torqued to specification, then using a boregauge measure the assembled ID of the bearings at 90 degrees to the parting faces.
The mating crankshaft journal size is measured, and subtracting this measurement from the bearing ID bore size,gives the assembled oil clearance.

ACL Race Series performance engine bearings can be assembled with .00075-.001” per 1” of journal diameter (0.020-0.025mm per 25mm of journal diameter) plus .0005” (0.013mm).

As an example for a 2.000” (50mm) journal diameter, 2.000 x .001 =
.002 + .0005 = .0025” (50/25 x 0.025 = 0.050 + .013 = 0.063mm).
Bearings should not be polished with abrasive pads or paper, on the bearing surface, to change the oil clearance!



[descextra]
Cross reference:
Dit artikel is ook geschikt:

10C5808 inklappen

Merk Model Motor Bouwjaar
FordCapri 1600, Lotus 1600 Twin CamOHV 8v (116E)All10C5808
FordCapri, Cortina Mk I, Mk II, Lotus 1500 Twin CamOHV 8v (116E)All10C5808
